Specifications36
Timing Chart
Supported timing for PC input
Supported timing for YP
bPr input
Resolution
Horizontal
Frequency
(kHz)
Ve r t ic a l
Frequency
(Hz)
Pixel
Frequency
(MHz)
Mode
720 x 400 37.927 85.039 35.500 720 x 400_85
640 x 480
31.469 59.940 25.175 VGA_60
37.861 72.809 31.500 VGA_72
37.500 75.000 31.500 VGA_75
43.269 85.008 36.000 VGA_85
800 x 600
35.156 56.250 36.000 SVGA_56
37.879 60.317 40.000 SVGA_60
48.077 72.188 50.000 SVGA_72
46.875 75.000 49.500 SVGA_75
53.674 85.061 56.250 SVGA_85
832 x 624 49.725 74.550 57.283 MAC16”
1024 x 768
35.522 86.957 44.900 XGA_43i
48.363 60.004 65.000 XGA_60
56.476 70.069 75.000 XGA_70
60.023 75.029 78.750 XGA_75
68.667 84.997 94.500 XGA_85
60.134 74.700 79.857 MAC19”
1152 x 864 67.500 75.000 108.000 SXGA1_75
1280 x 960 60.000 60.000 108.000 QuadVGA_60
1280 x 1024 63.981 60.020 108.000 SXGA3_60
Signal Format
Horizontal Frequency
(kHz)
Vertical Frequency (Hz)
480i(525i)@60Hz 15.73 59.94
480p(525p)@60Hz 31.47 59.94
576i(625i)@50Hz 15.63 50.00
576p(625p)@50Hz 31.25 50.00
720p(750p)@60Hz 45.00 60.00
720p(750p)@50Hz 37.50 50.00
1080i(1125i)@60Hz 33.75 60.00
1080i(1125i)@50Hz 28.13 50.00
