Configuration and calibration tool control
RS232
• Connect the RJ45 - RS232 cable to the RS232 - USB cable with computer for RS232
control.
• Make sure the dip switch is in RS232.
LAN
• Connect the LAN cable from the display LAN port to a router.
• Make sure the dip switch is in LAN.
• Connect the computer to the router via the LAN cable or wireless link.
USB
RS232 IN
PC
RJ-45
ROUTER
LAN
