Specifications22
Specifications
Touch module
Model Name PT01
Operating Voltage 4.7~5.2V
Power Consumption Max 180mA
USB Type (Power) Mini USB B type
Power Source Power via USB connector or 5V adaptor
Wavelength 850nm ± 10nm
Fan Angle Max : 180° (1 laser beam)
Rolling Control Range Max 4°
Pitch Control Range Max 3.5°
Safety Class 1
Dimension 178.85 x 58.09 x 40.10mm
Weight 152g (with cover)
General function
Camera Type PointWrite series camera module
Multi Pen Supported Up to 4 touch points (Pen/Finger)
Response Time 0.016 sec
Refresh Rate 60 Frames/sec
Calibration Auto / Manual16 points
Dual screen Calibration Yes
USB Cable Distance Max 15meter (5meter USB cable + repeater)
