BenQ PT01 - Product Overview; About PT01; Dimensions

Product Overview4
About Dummy Pen
When replacing the pen nib on the dummy pen, take it from the dummy pen.
Product Overview
About PT01
Right View
Dimensions
For better touch performance, keep the pen nib clean.
When replacing the pen nib, take it
from the dummy pen.
Front View Rear View
Cover
Top screw
Left screw Right screw
Attach tape area
Touch module head
Mounting
hole
Mounting
hole
USB port
178.85mm
58.09mm
40.10mm
