Q7C3 LCD Monitor Service Guide
Engineering Specification
17
5. Physical Specifications
5.1 Physical Dimension & Appearance
5.1.1 Overall Dimensions:
375mm (W) X 370mm (H) X 155mm (D)
5.1.2 Outer Appearance:
see Fig.1
5.2 Construction and Materials on outer surface
(1) Materials: Plastic
(2) Color: To be defined for Model
5.3 Base
(1)Tilt: fiest hinge:0°~ 25°
5.4 Marking & Labels
5.4.1 Reference Label (Rear panel)
(1) Reference numbers
(2) Manufacture data
(3) Agency Approvals
(4) Power Ratings
5.4.2 Controls & Connectors
(1) AC power cord input: abbreviated labels
(2) User's Controls: standard print
5.5 Packaging
5.5.1 Carton Dimension:
456mm (W) X423mm (D) X 146mm (H) (LCD monitor)
5.5.2 Shipping Weight:
5.8kg
(LCD monitor)
5.5.3 Shipping Container:
1960 sets per 40 feet container with pallet.
6. Maintainability Specifications
6.1 General & Requirements
6.1.1 Installation:
From outside of unit with standard tools and documentation provided to user.
6.1.2 Periodic Maintenance:
No periodic maintenance is required.
6.1.3 Repair & Calibration:
Require spare modules or components as specified as followings:
(1) Interface board ASSY
(2) AC-DC converter board ASSY
(3) Control board ASSY
6.2 Mean Time to Repair
6.2.1 Module Level:
Less than 10 minutes
6.2.2 Component Level:
Less than 15 minutes
