Q7C3 LCD Monitor Service Guide
Engineering Specification
8
2.3.3 Pallet Specification
a. Dimension
Transport Type Pallet A Pallet B Pallet C
Pallet D
Length 812 812 406
406
Width 836 1254 836
1254
Shipping Pallet
Dimension (mm)
Height 115 115 115
115
Length X X X
X
Width X X X
X
Air Transport Pallet
Dimension (mm)
Height X X X
X
2.3.4 Container Carrying Capacity
a. Shipping Container
Quantity of products
(sets)
Quantity of Products
(sets)
Quantity of pallet
(sets)
Stowing Type
(Every container)
(Every Pallet) (Every Container)
910 Pallet A: 56 Pallet A: 6
20'
Pallet B: 84 Pallet B: 6
Pallet C: 28 Pallet C: 1
Pallet D: 42 Pallet D: 1
40'
1960 Pallet A: 56 Pallet A: 14
with pallet
Pallet B: 84 Pallet B: 14
2.4 Electrostatic Discharge Requirements
The subject product must withstand 8 KV for contact discharge and 15 KV for air discharge of Electrostatic
Discharge and meet the acceptance criteria as specified IEC 801-2 .
2.5 Safety Requirements
The display unit complies with the following safety standards and specifications.
-UL compliance....standard for information-processing and business equipment, UL 1950.
-CSA compliance...standard C22.2 No. 950-M89, data processing equipment.
-TUV compliance...EN60950 safety specification-business equipment.
-ISO13406-2 .Ergonomic Requirements of Visual Display.
-Demko...EN60950.
-Nemko...EN60950.
-Semko...EN60950.
-Fimko...EN60950.
2.6 EMI Requirements
1. This display unit complies with the following EMC rules and regulations.
-FCC compliance...FCC Rule, Part 15, Subpart B, Class B.
-VCCI compliance...VCCI Rule, Class-2.
-CE Mark Compliance... 89/336/EEC.
EN55024, EN61000-4-2/-3/-4/-5/-6/-8/-11
EN55022, Class B.
EN61000-3-2,EN61000-3-3.
