Q7C3 LCD Monitor Service Guide
Engineering Specification
18
6.3 Accessibility
6.3.1 General:
All panels, covers, and major assemblies are removable without disruption of permanent mounting or fasteners.
6.3.2 Outside Cabinet, access to the following elements
-Operating Controls
-AC Inlet
-Audio in
6.3.3 Cover Removal, Access
All sub assemblies and internally adjustable components may be accessed by removing the base and
the rear cover .
6.4 Equipment & Tools Required
6.4.1 Standard Test Equipment
(1) Voltmeter
(2) Dual trace oscilloscope
(3) Hand tools as required
(4) Computer with IBM VGA , or compatible graphic adapter
6.4.2 Documentation
A service manual will be available which covers all service requirements. A users manual written
in Japanese German, Italian, Spanish, France and English will be available to ship with the product.
6.5 Electrical Emission and Energy Saving summary for TCO03
6.5.1 Electrical Field(AC):
*Band I< 10V/m (132cd/m^2,”+” pattern)
*Band II< 1V/m (132cd/m^2,”+” pattern)
Note: Shielded power cord is not acceptable
6.5.2 Magnetic Field(AC):
*Band I< 200nt (132cd/m^2,”+” pattern)
*Band II< 32nt (132cd/m^2,”+” pattern)
Note: Shielded power cord is not acceptable
6.5.3 Energy Saving:
*1
st
stage:<15W(recover time:3 sec)
2
nd
stage:<5W
*single stage:<5W(recover time: 3sec)
Appendix 1 – Shipment Conditions
ITEM
State
Power ON
Brightness 90
Contrast 50
OSD- Timeout 10s
OSD-Language English
OSD-Image size Full Screen
OSD-Color temp CU MODE
