BENQ LCD FP767-12 Q7C3 Spare Parts List
P/N: 99.L9072.RBA/RBE
ITEM DESCRIPTION PART NO. LOCATION
1 PCBA I/F BD Q7C3-12MS AU 55.L9001.021
2 IC FLASH MTV312MV64 (AJ) PLCC4 71.31264.A03 U4
3
IC LVDS/RSDS MVPRL-HN PQPF 160P 71.MVPRL.A0E U2
4
IC EEPROM AT24C04N-10SI-2.7SON 72.02404.N01 U3
5
IC CMOS 74LVC14A SO-N 14P 73.07414.061 U1
6
IC LR AME8815AEGT250 SOT-223 74.08815.C3C U5
<ALT>
IC VR G950T65U SOT-223 74.95065.03C
7 PCBA SPS BD Q7C3-12MS 55.L9002.003
8 PCBA CTRL BD Q7C3 55.L9003.011
9 LCDM 17" M170EN05 V8 Q7C3/AUO 56.91L90.011
10 ASSY BZL T7032C Q7C3 (FP767-12) 60.L9001.061
11 ASSY UC ABSHB T7032C Q7C3 60.L9002.011
12 ASSY COLUMN ABS T7032C Q7C3 60.L9003.012
13 ASSY BKT-MAIN Q7C3 AUSIP W/SPK 60.L9020.002
14 CORD SVT #18*3C 10A125V US1.5M 27.01818.051
15 CORD H05VV-3G 10A250V EURO 27.02718.051
16 CTN B Q7C3/BENQ Q7C3 44.L9001.002
17 CSN L EPS Q7C3/PAINTING Q7C3 47.L9013.001
18 CSN R EPS Q7C3/PAINTING Q7C3 47.L9014.001
19 CABLE AUD PC99PT284C/PT577C BK 50.74405.501
20 CABLE SIGNAL 15/15P CORE*1 1.5M 50.L9005.501
21 CD FP767-12/756-12MS Q7C3-12MS 53.L9003.001
22 ASSY BASE ABS T7032C Q7C3 60.L9004.012
* THIS PARTS LIST MAY BE SUBJECT TO CHANGE
WITH PRIOR NOTICE BY CSD OF BENQ.
