Parts of the display and their functions12
YPbPr 2
Receives component video (YPbPr) signals from an external device
via 3.5mm RGB component video cable.
AV OUT
Outputs composite video signals from the AV IN input to another
display with a 3-in-1 3.5mm RCA cable.
SPDIF Out
Outputs digital audio signals via a coaxial cable to an external
device.
Earphone Connects to a headphone or an earphone.
Sound Box L R Connects to external stereo speakers.
M USB Accesses multimedia files on USB drives directly.
Power Connects to a power outlet via the supplied power cord.
PC USB Extends the USB port of computer to PC USB at front.
• TOUCH 1 must be used with HDMI 1 or VGA 1, and TOUCH 2 must be used with HDMI 2
or VGA 2.
• Either front or back PC USB has to be adopted for the other functioning as a USB extender.
