Connection20
Connecting the touch module
Connect the USB TYPE A FOR TOUCH (type A) jack (TOUCH 1, TOUCH 2, or
TOUCH 3) on the display to the USB port of a computer using the supplied USB cable.
The touch module of the display supports easy Plug-and-Play operation. There is no need
to install additional drivers on the computer.
• Avoid blocking the touch screen frame (where sensors are located) when initiating the touch
module.
• It is highly recommended that you connect the display to the PC or laptop directly. Avoid
connecting the display to a face plate device which may cause failures in touch operations.
• If any ghost image occurs, please try to un-plug and then re-plug all USB cables. If the failure
image still exists, use another USB type A to A cable.
• TOUCH 1 must be used with HDMI 1 or VGA 1, TOUCH 2 must be used with HDMI 2 or
VGA 2, and TOUCH 3 must be used with HDMI 3 or VGA 3.
