BenQ SL6501 - IR Connection

Connecting External Equipment22
PC
DVI-I
DVI-I IN DVI/DVI-I OUT DVI-I IN
DISPLAY 1 DISPLAY 2
Analog Daisy chain to 9 units without splitter.
IR connection
IR IN IR OUT IR IN
DISPLAY 1 DISPLAY 2
External
IR Receiver
1. This display’s remote control sensor will stop working if the IR IN is connected.
2. IR loop through connection can support up to 9 displays.
