23 How to assemble your monitor hardware
Rotating the monitor
Rotate the monitor before installing the shading hood. See Portrait installation on page 19 for more information.
1. Pivot the display.
Before rotating the monitor with a portrait viewing orientation, the display has to be rotated 90
degrees.
Right-click the desktop and select Screen resolution from the popup menu. Select Portrait in
Orientation, and apply the setting.
Depending on the operating system on your PC, different procedures should be followed to adjust the screen
orientation. Refer to the help document of your operating system for details.
2. Fully extend the monitor and tilt it.
Gently lift the display up and extend it to the maximum
extended position. Then tilt the monitor.
The monitor should be vertically extended to allow to rotate
from landscape to portrait mode.
3. Rotate the monitor 90 degrees clockwise as
illustrated.
To avoid the edge of the LCD display hitting the monitor base
surface while it is being rotated, do tilt and extend the monitor
to the highest position before you start to rotate the display. You
should also make sure there are no obstacles around the monitor
and there is enough room for cables. Remove the connected USB
peripherals and audio cable first.
90

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BenQ SW240 and is the answer not in the manual?

BenQ SW240 Specifications

General IconGeneral
3DNo
Pixel pitch0.27 x 0.27 mm
Screen shapeFlat
Display diagonal24.1 \
Display technologyLED
Native aspect ratio16:10
Vertical scan range50 - 76 Hz
Maximum refresh rate76 Hz
Horizontal scan range30 - 83 kHz
Contrast ratio (dynamic)20000000:1
Contrast ratio (typical)1000:1
Display number of colors1.073 billion colors
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
On/off switchYes
TV tuner integrated-
CertificationTUV GS, CE, ISO9241-307
Product colorGray
Country of originChina
Market positioningGraphics design
HDCP version2.2
USB hub version3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity3.5 mm
Compatible memory cardsSD, SDHC, SDXC
USB Type-A downstream ports quantity2
Tilt angle range-5 - 20 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
AC input voltage90 - 264 V
AC input frequency47/63 Hz
Energy efficiency scaleA to G
Power consumption (off)0.2 W
Power consumption (standby)0.3 W
Power consumption (typical)18.1 W
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 90 %
Cables includedAC, DVI, USB
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)230.71 mm
Width (with stand)543.51 mm
Height (with stand)428.5 mm
Weight (with stand)6700 g
Width (without stand)- mm
Weight (without stand)- g
