BenQ SW240 User Manual

30 Getting the most from your BenQ monitor
How to install on Windows 8 (8.1) system
1. Open Display Properties.
Move the cursor to the lower-right of the screen or press the Windows + C buttons on the
keyboard to bring up the Charm bar. Go to Settings, Control Panel, Devices and Printers
and right-click the name of your monitor from the menu.
Alternatively, right-click the desktop and select Personalize, Display, Devices and Printers,
and right-click the name of your monitor from the menu.
2. Select Properties from the menu.
3. Click the Hardware tab.
4. Click Generic PnP Monitor, and then the Properties button.
5. Click the Driver tab and the Update Driver button.
6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer.
7. In the Update Driver Software window, select the option Browse my computer for
driver software
.
8. Click Browse and navigate to the following directory: d:\BenQ_LCD\Driver\ (where d is
the drive letter designator for the CD-ROM drive).
9. Select the correct folder name of your monitor from provided driver list, and click Next.
This will copy and install the appropriate monitor driver files to your computer.
10. Click Close.
You may be prompted to restart your computer after the driver update is complete.
The drive letter for your CD drive may differ from the example above depending upon your system - it may be
'D:' or 'E:' or 'F:' etc.

BenQ SW240 Specifications

General

3D	No
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Display diagonal	24.1 \
Display technology	LED
Native aspect ratio	16:10
Vertical scan range	50 - 76 Hz
Maximum refresh rate	76 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
TV tuner integrated	-
Certification	TUV GS, CE, ISO9241-307
Product color	Gray
Country of origin	China
Market positioning	Graphics design
HDCP version	2.2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
Compatible memory cards	SD, SDHC, SDXC
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 264 V
AC input frequency	47/63 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.2 W
Power consumption (standby)	0.3 W
Power consumption (typical)	18.1 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 90 %
Cables included	AC, DVI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230.71 mm
Width (with stand)	543.51 mm
Height (with stand)	428.5 mm
Weight (with stand)	6700 g
Width (without stand)	- mm
Weight (without stand)	- g
