13
RESETTING THE SERVICE ALARM
After a service alarm has been activated you are able to reset the hours setting without the need to reprogram
the telephone number by selecting Reset from the Configuration/Reset screen.
SYSTEM RESET
This function resets the Benson CP4’s settings back to the factory default.
To put the control through a reset:
• Press 4 for Setup
• Press 4 for Extra
• Press 2 for Reset
• Pressing ENTER at this point will erase all data. To abort press the DELETE Key.
RESET ALL DATA?
ENTER TO CONFIRM
Enclosure: ABS Fire Retardant
Dimensions: 222mm x 156mm x 61mm (Length, Height,Depth)
Weight: 1.3 kg
Relays: Relay 1-3 normally open contacts
Relay 4 normally open, normally closed contacts
10 amp 230v rating relays 1-3
Alarm Input: 230v AC. 5mA Max.
Supply: 230v AC ± 10% 50Hz
Sensors: Only use Heatmiser Sensors. Twin screened cable (Beldon 8451)
Battery: 3 years (Replacement battery: CR2430)
Fuses: FS1: 800mA Antisurge
FS2: 315mA Quick blow
FS3: 315mA Quick blow
SYSTEM SPECIFICATIONS
