REMOTE
SENSORS
+
1
2
+
-
INPUT1
INPUT2
12V
S
+
-
S
SENSOR2
(OPTIONAL)
1
+
-
S
SENSOR
proving
switch
(Optional)
Override
switch
(Optional)
Sensor and input wiring
Beldon 8451 (RS 360-649) Twin, Screened cable
must be used when connecting the remote sensors
MISTRAL
1
1
01
14
CP4
