Bentone B 10 E R - Technical Data; Dimensions and Flange Specifications; Output Range and Nozzle Recommendations; Electrode Adjustment and Air Regulation

6,0-8,0
Dimensions
171 215 21 07-01
TECHNICAL DATA
Electrode adjustment
Because of different boiler types
existing on the market, with varying
combustion chamber designs, it is

angle or spray pattern.
Recommended nozzle
Note that the spray angle and the
spray pattern change with the pump
pressure.
Output range and nozzles recommended
Flange A
Flange B
Flange C
ø89,5
21
10,5
130-150
ø89,5 26
130-150
12
ø89,5
12
130-150
12

Burner tube Length of
burner tube
Flange A
Measure B
Flange B
Measure B
Flange C
Measure B
E 77 52 47 61
E 124 99 94 108
E 154 129 124 138
E 215 190 185 199
Burner tube Oil capacity Capacity Recommended
Nozzle
Recommended
Pump pressure
   Angle Size Type Bar
E 2,35-4,1 28-49 24-42 60°, 80° 0,50-1,00 S or R 10
ø89
202
B
155
94
148
296
7
2,4-3,2
10,0-11,0
(- 1,0) - 0,0
