19
Because your TC505 can be used in a wide range of
applications some operating parameters of the
controller are adjustable. Usually if there were any
adjustments required they already have been done by
your supplier. Please refer to following parameter list If
you are interested in details:
Failure in setting up the parameter might easily cause
damage to kiln and firing goods. It is the users
responsibility to decide whether the changes made
are proper and safe. If you are in doubt do not adjust
the parameters !
Some adjustments are blocked for safety reasons (e.g.
changing the type of thermocouple from S/R to J/K or
vice versa).
Warning !
Appendix C
Configuration
par.-no. description default unit
1 power of kiln 0,0 kWh
2 < reserved > 0 cm/h
3 type of thermocouple (S, R, K, J) -
4 maximum temperature of the kiln 1320 °C
5 proportionalband 2.0 %
6 integral time 200 s
7 derivative time 10 s
8 cyclus time (or hysteresis resp., 1.0°C) 30 s
9 reaction on heat up problems 1 -
10 number of kiln zones 1 -
11 enter ramps as gradient (°C/h) or time (h.min) grad grad/time
12 function of the 1st additional control output 1 -
<13> function of the 2nd additional control output 0 -
<14> function of the 3rd additional control output 0 -
