The document describes the Personal Portable DAB Radio H300, a compact and lightweight digital radio designed for on-the-go use.

Function Description:

The H300 is a pocket-sized DAB/DAB+/FM radio that allows users to listen to a wide range of digital and FM radio stations. It is ideal for outdoor activities, gardening, DIY, or general portable listening. The device features a backlit LCD display, a built-in rechargeable battery, and includes headphones which also serve as the aerial. It supports both DAB (Digital Audio Broadcasting) and FM (Frequency Modulation) with RDS (Radio Data System) for enhanced information display.

Important Technical Specifications:

Model: H300
Radio Type: DAB/DAB+ and FM (RDS)
Frequencies Digital: Band III 174-240MHz
Frequencies FM: 87.5-108MHz
Headphones: 32ohm, 14mm diameter driver (included)
Receiving Power Supply: 5V(1A) DC micro-USB (cable supplied)
Battery: Lithium-ion rechargeable battery (1000mAh)
Battery Life: Up to 10 hours of listening on one full charge
Inputs: 5VDC (1A) Micro-USB power socket
Outputs: 3.5mm stereo headphone socket
Presets: 10 digital presets, 10 FM presets
Operational Temperature: 0°C to +40°C
Dimensions: 90mm (H) x 51mm (W) x 16mm (D)
Weight: 100g
Aerial: Supplied in-ear headphones act as the aerial.

Usage Features:

Portability: Small enough to fit in a pocket, making it highly portable.
Station Access: Provides access to up to 250 commercial and 34 BBC radio stations, plus FM broadcast.
Presets: Features 20 station pre-sets (10 DAB, 10 FM) for quick access to favourite stations.
Display: LCD backlit display for clear visibility.
Headphones: Includes 3.5mm stereo output headphones (approx. 112cm length).
Charging: Recharges via a micro-USB cable (supplied) and can be connected to a USB power adapter (not supplied) or a computer's USB port.
Initial Setup: Requires charging the battery for at least 8 hours before first use. Headphones must be connected as they function as the aerial.
Power/Lock Switch: A slide switch controls power and locks buttons to prevent accidental presses.
DAB Mode:
- Auto Tune: Automatically tunes to digital radio stations upon switching on.
- Display Information: MENU/INFO button allows cycling through various display information such as DLS (Dynamic Label Segment), signal strength, PTY (Programme Type), ensemble, frequency, signal quality, bit rate codec, time, and date.
- Menu Options: Press and hold MENU/INFO to access menu options: Full Scan, Manual Tune, Prune, and System.
- Full Scan: Scans for all available DAB stations.
- Manual Tune: Allows manual tuning to specific DAB channels/frequencies, displaying live signal strength.
- Prune: Removes invalid stations from the station list.
- Time Settings: Automatically updates time via DAB signals or can be set manually, with options for 12/24 hour format and date format.
- Backlight: Adjustable backlight timeout (Medium, High, Low).
- Factory Reset: Clears all user-defined settings and restores default values.
- Software Version: Displays the current software version.
FM Mode:
- Switching: Press the MODE button repeatedly to switch to FM mode.
- Manual Frequency Change: TU+/- buttons allow changing FM frequency by 0.05MHz.
- Display Information: MENU/INFO button allows cycling through display information such as radio text, PTY (Programme Type), PS (Programme Service), stereo/mono, time, and date.
- Menu Options: Press and hold MENU/INFO to access menu options: Scan Setting, Audio Setting, and System.
- Scan Setting: Options to scan for "Strong stations only" or "All stations."
- Audio Setting: Options for "Stereo allowed" or "Forced mono" to improve audio quality for weak stations.
Volume Control: A volume dial adjusts the listening level.
Station Selection: Next/Previous buttons cycle through radio stations or menu options.
Preset Storage/Recall: Press and hold the PRESET button to store a station, then use Next/Previous and SELECT to choose a preset number. Press PRESET once to recall a stored station.

Maintenance Features:

Safety Instructions: Emphasises reading and retaining safety instructions, including proper handling of liquids, temperature exposure, and battery care.
Cleaning: Unplug from power supply before cleaning. Do not use abrasive pads or cleaning solutions.
Battery Care: Keep batteries away from children/pets, do not mix old/new batteries, remove if unused for long periods, never dispose in fire, and follow local regulations for disposal.
Battery Reset: If controls stop responding, a battery reset can be performed by pressing the reset button on the side of the radio with a paper clip.
Repairs: Product repairs should only be carried out by authorised personnel; users should not remove screws or attempt internal repairs.
Disposal: Packaging is recyclable. At the end of its lifespan, the product should be disposed of at an authorised household waste recycling centre. Plastics (LDPE) used in packaging are recyclable.

Bergstrom H300 - Product Overview; Connections
