2
Model 3PL Model 5PL
Pressure in PSI Pressure in PSI
Feet to 20 30 40 50 60 20 30 40 50 60
Water GPM with J32P-24 Venturi and #54 Nozzle GPM with J32P-24 Venturi and #51 Nozzle
30 9.8 7.2 4.5 2.2 – 10.0 8.8 6.5 4.1 2.1
40 8.3 5.8 3.5 1.4 – 9.0 7.5 5.1 3.0 1.0
50 7.0 4.5 2.3 – – 8.3 6.4 4.0 2.0 –
60 5.5 3.3 1.3 – – 6.8 5.0 3.0 1.0 –
70 –– – – –5.6 4.0 1.8 – –
80 –– – – –4.0 2.5 0.75 – –
PERFORMANCE
TABLE I – 4” Double Pipe Deep Well Performance and Ejector Chart -
Ejector Package BK4800
Model 3PL Model 5PL
Pressure in PSI Pressure in PSI
Feet to 20 30 40 50 60 20 30 40 50 60
Water GPM with J32P-72 Venturi and #51 Nozzle GPM with J32P-63 Venturi and #51 Nozzle
5 9.5 9.2 9.0 5.8 3.0 16.2 15.8 15.3 8.7 1.3
10 8.2 8.0 7.8 5.2 2.3 14.2 14.0 13.8 7.2 –
15 7.2 6.8 6.8 4.5 1.8 12.2 12.0 11.8 5.3 –
20 5.7 5.7 5.7 3.8 – 9.7 9.7 9.2 3.7 –
25 4.3 4.3 4.3 3.2 – 7.2 6.8 6.8 – –
Model 3PL Model 5PL
Pressure in PSI Pressure in PSI
Feet to 20 30 40 50 20 30 40 50
Water GPM with J32P-24 Venturi and #54 Nozzle GPM with J32P-24 Venturi and #54 Nozzle
30 9.7 7.0 4.5 2.8 10.0 8.6 6.2 3.8
40 8.1 5.4 3.3 2.3 8.8 7.25 4.8 2.75
50 6.7 4.0 2.6 1.7 8.5 6.0 5.5 1.6
GPM with J32P-18 Venturi and #52 Nozzle
60 3.8 2.9 2.0 1.1 4.2 3.3 2.6 1.9
70 3.2 2.3 1.5 0.7 3.6 2.8 2.1 1.3
80 ––––3.0 2.25 1.6 1.0
90 ––––2.5 1.75 1.2 0.6
100 GPM with J32P-18 Venturi and #52 Nozzle 2.0 1.3 .75 –
TABLE II – 2” Single Pipe Deep Well Performance and Ejector Chart -
Ejector Package BK4830, BK4840
TABLE III – Shallow Well Performance and Ejector Chart - Ejector Package BK4875
