OWNER’S MANUAL

Shallow Well Jet Pumps/

Tank Systems

Installation/Operation/Parts

For further operating, installation, or maintenance assistance:

Call 1-800-363-PUMP (7867)

© 2006 BE424 (Rev. 4/23/09)

Series “HN” and “SN”

293 Wright Street • Delavan, WI 53115

Table of Contents

Questions and Answers

C
Christopher StantonAug 5, 2025
How to troubleshoot a Berkeley 10SN motor that will not run?
- S
  spadillaAug 5, 2025
  If your Berkeley Water Pump's motor won't run, first ensure the disconnect switch is on. If it still doesn't work, check the fuse and replace it if it's blown, or reset the circuit breaker if it's tripped. If those aren't the issue, the starting switch might be defective and need replacement, but be sure to disconnect power first. Also, inspect the wires at the motor to ensure they are tightly connected and wired correctly, again, after disconnecting power. Lastly, if the pressure switch contacts are dirty, disconnect the power and clean them with an emery board or nail file.
M
Melissa MilesAug 10, 2025
What to do if my Berkeley 10SN Water Pump delivers water but does not shut off?
- M
  Michael Garcia DVMAug 10, 2025
  If your Berkeley Water Pump delivers water but doesn't shut off or cycles too frequently, first, disconnect power and adjust or replace the pressure switch. Check if any faucets have been left open and close them. Inspect and clean the venturi, nozzle, or impeller if they are clogged. If you have a standard pressure tank that is waterlogged, drain the tank to the air volume control port. Check all pipe connections for air leaks and replace the foot valve if it's leaking. Finally, if you have a pre-charged tank, disconnect power, relieve pressure, and check the air pressure; adjust it to 2 PSI less than the cut-in setting of the switch, and check for leaks at the air valve.
R
Richard AyalaAug 15, 2025
Why does my Berkeley 10SN motor run hot and overload kicks off?
- W
  William EdwardsAug 15, 2025
  If your Berkeley Water Pump motor runs hot and the overload kicks off, the motor might be wired incorrectly, so refer to the wiring instructions. Also, the voltage may be too low, in which case you should check with your power company. If the pump cycles too frequently, install heavier wiring, referencing the Electrical/Wiring Chart for proper wire size.
R
Rebecca AllenAug 26, 2025
Why is my Berkeley 10SN Water Pump not delivering water to full capacity?
- H
  hinesthomasAug 26, 2025
  If your Berkeley Water Pump does not deliver water to full capacity, it could be due to several reasons. If the water level in your well is lower than estimated, a deep well jet may be needed if the depth to water exceeds 25 feet. If you're using steel piping, corrosion or liming could be causing excess friction; consider replacing it with plastic pipe or new steel pipe. Also, ensure that the piping isn't too small; using larger piping can help. Lastly, a packed well point can restrict water flow; backflush the well point or sink a new one.
P
Paul AndersonAug 30, 2025
Why does my Berkeley Water Pump have air spurts from the faucets?
- A
  amy90Aug 30, 2025
  If your Berkeley Water Pump is spurting air from the faucets, it might be picking up prime; once it has primed, it should pump solid water without air. Check the suction side of the pump for leaks using soapy water. If the well is gaseous, consult the factory about installing a sleeve in the well. Intermittent over-pumping can also cause this; lower the foot valve if possible, or restrict the pump discharge.
H
Heather KelleyNov 19, 2025
What to do if my Berkeley 10SN Water Pump motor runs but no water is delivered?
- B
  Bruce HernandezNov 20, 2025
  If your Berkeley Water Pump motor runs but no water is delivered, and it's a new installation, re-prime the pump according to the instructions. Also, check all connections on the suction line, AVC, and ejector with soapy water or shaving cream. Replace the foot valve or check valve if necessary. If the pump has lost prime in an existing installation, check all connections on the suction line and shaft seal. You can also lower the suction line into the water and re-prime. Additionally, clean the foot valve or strainer if they are plugged, as well as the ejector or impeller. Replace the check valve or foot valve if they are stuck shut. Thaw any frozen pipes. Raise the foot valve and/or strainer above the bottom of the water source if they are buried in sand or mud. If the water level is too ...

Summary

Safety

General Safety Instructions

Explains the safety alert symbol and hazard definitions.

Electrical Safety

Details electrical hazards and precautions for pumps.

General Safety Precautions

Outlines essential safety practices for pump operation.

Specific Safety Warnings

Highlights critical warnings regarding voltage and pressure hazards.

Installation

Replacing an Old Pump

Step-by-step guide for removing and replacing an existing pump.

Well Point Installation

Instructions for installing pumps for driven point wells.

Cased Well Installation

Procedures for installing pumps in cased wells.

Surface Water Installation

Steps for installing pumps for surface water sources.

Discharge Pipe and Pressure Tank Connections

Pre-Charge Tank Connection

Guide for connecting the pump to a pre-charged pressure tank.

Standard Tank Connection

Instructions for connecting to a standard pressure tank system.

Electrical

Motor Switch Settings

Adjusting dual-voltage motors for specific voltage requirements.

Pressure Switch Wiring

Correctly wiring the pressure switch for pump operation.

Wiring Connections and Chart

Connecting power supply and selecting wire sizes based on distance.

Preparing to Start the Pump

Priming the Pump

Step-by-step procedure to prime the pump and piping for operation.

Repair Parts

Exploded View

Visual breakdown of pump components for specific models.

Repair Parts List

Detailed list of part numbers for pump models.

Service Kits

Information on available service and overhaul kits.

Troubleshooting

Berkeley 10SN Specifications

General

Type	Centrifugal Pump
Horsepower	10 HP
Max Flow Rate	500 GPM
Max Head	150 feet
Voltage	230/460 V
Housing Material	Cast Iron
Impeller Material	Bronze
Shaft Seal	Mechanical Seal
