9
BERNAFON CHRONOS
Chronos Nano BTE
1 Push out the metal pin with the disassembly tool.
2 Pull the pin out with a pair of tweezers.
3 When replacing the drawer, snap in the new drawer (closed position) and use the tweezers to place
the pin into the hole.
4 Use the at end of the tweezers to push the pin completely in.
VR_ILU_NanoBTEbatteryDrawerRemove1_CMYK_HI
VR_ILU_NanoBTEbatteryDrawerRemove2_BW_HI
VR_ILU_NanoBTEbatteryDrawerMounting_BW_HI
Tamper resistant battery drawer
The following models have an optional tamper resistant battery drawer that can be ordered separately.
Micro BTE CP and CPx BTE
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerCompactBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE2_BW_HI
