SoundGate 3 overview
1 Power ON/OFF
2 LED indicator
3a Volume up key
3b Volume down key
4 Auxiliary input key
5 TV key
6 Phone key
7 Microphone inlet
8 Neck strap jacks
9 3.5 mm auxiliary input
10 Micro-USB charger
jack
SN2_ILLU_Overview_HI
8
SN2_ILLU_SoundgateProfile_HI
1
4 5 6 7
10
9
8
3b
3a
2
1
8
