Bernette Straight Stitch B08 - Threading the Upper Thread

SEWING PREPARATION
22
2024-06 EN 5020105.00A.04
> Pull both threads approx. 4in (10cm) to the back and place them under the presser foot.
Threading the Upper Thread
> Switch the machine off.
> Raise the needle.
> Raise the presser foot.
> Place the thread spool on the spool pin so that the thread unwinds clockwise.
> Place the thread from the back through the thread guide.
> Pass the thread through the thread guide plate(1) and then insert the thread between the thread tension
discs(2) of the adjusting wheel for the thread pre-tension. Note: If the thread tends to twist a lot, feed
the thread through the 3 holes in the thread guiding plate (A), as shown in illustration (A).
A
1
2
> Hold the thread with both hands and place it clockwise around the thread tension adjustment wheel(1).
Guide the thread over the end of the thread guide spring(2). Pass the thread from bottom to top into
the thread guide(3).
1
2
3
