2.3 Installation niche requirements:
Stainless Integrated Series
A - area to be left clear for the anti-tipping brackets
Niche Height
min 2064 (81 1/4”)
Niche Width
900 mm (35 1/2”)
750 mm (29 5/8”)
Door Swing Clearance
1470 mm (57 7/8”)
1320 mm (52”)
Door Opening Angle
105°
Width
899 mm (35 3/8”)
749 mm (29 1/2”)
Height
2050 mm (80 3/4”) + 25 mm (1”)
Depth with door (without panel)
635 mm (25”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”) 100 (4”)
min 2064 (81 ¼”)
90: 900 (35 ½”)
75: 750 (29 ⅝”)
635 (25”)
560 (22”)
0T
693 (27 ¼”)
2050 (80 ¾”) +25 (1”)
1308 (51 ½”)587 (23 ⅛”)
146 (5
¾”)
+ 25(1”)
9 ( ⅜”)
732 (28 ⅞”)+25 (1”)
105°
90: 1470 (57
⅞”
)
75: 1320 (52”)
90: 230 (9”)
75: 195 (7 ¾”)
90: 899 (35 ⅜”)
75: 749 (29 ½”)
10 (⅜”)
75 (3”)
58 (2 ¼”)
1016 (40”)
635 (25”)
560 (22”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”) 100 (4”)
min 2064 (81 ¼”)
90: 900 (35 ½”)
75: 750 (29 ⅝”)
635 (25”)
560 (22”)
0T
693 (27 ¼”)
2050 (80 ¾”) +25 (1”)
1308 (51 ½”)587 (23 ⅛”)
146 (5 ¾”) + 25(1”)
9 ( ⅜”)
732 (28 ⅞”)+25 (1”)
105°
90: 1470 (57
⅞”
)
75: 1320 (52”)
90: 230 (9”)
75: 195 (7 ¾”)
90: 899 (35 ⅜”)
75: 749 (29 ½”)
10 (⅜”)
75 (3”)
58 (2 ¼”
)
1016 (40”)
635 (25”)
560 (22”)
