3. INSTALLATION INSTRUCTIONS
INSTALLING THE BOTTOM CABINET
Complete the water connection
• Use a cutter to cut of any excess waterline
length, allowing sucient slack of 10” (254 mm)
to ensure an easy bend and clear connection,
with no tension or potential kinks in the supply
line that runs to the connector.
• Use 2 wrenches to firmly connect both the hose
that runs from the supply and the connection to
the valve on the refrigerator.
WARNING:
The hose that runs from the water supply
must be one piece. Do not use extension
hoses.
WARNING:
Make sure that the power is cut o
when establishing the appliance's water
connection.
WARNING:
The water valve must be closed when
connecting the water hose.
WARNING:
It is recommended to keep the water valve
accessible after product installation.
WARNING:
This appliance is suitable for use with a
cold potable water supply only.
WARNING:
The pressure of the water system must be
between 25-80 psi (1.7-5.5 Bar).
NOTE:
Once the connection is complete, you must
open the water valve and make sure that
there is no leakage.
ATTACHING THE AIR VENT GRILLE
• Use 5 screws to attach the vent aperture
component.
254 mm
