12
7
8
4
5
Series: Integrated (BI)
Position the brackets on each set of marks to make sure they are
aligned
4
, you may wish to drill pilot holes (pay close attention to
the panel’s thickness)
5
.
Screw the brackets in place
6
.
Drawer Panel
When preparing the Drawer Panel, follow the same instructions as
per the door panel, but make sure measurements are taken starting
from the top edge
7
. The support bracket faces the opposite way
8
(note imgs 4 and 8).
