Series: Stainless (BKI)
Mounting handles on stainless front
To mount the handles onto the door and the drawer operate as follows:
Operate as follows:
Insert the two handle spacers onto the mounting studs already avail-
able on the door and the drawer
1
. Ensure the mounting studs are
not loose.
Screw in the Allen set-screws pre-installed on the handle
2
.
The screws must be tightened in by means of a 2.5 mm (1/8”) hex
wrench / Allen key. Take care not to damage or scratch the stainless
panel with the tool.
