Bertazzoni REF30PIXL - Installation; Connection to the Electrical Power Supply

5
140 (5 ½”) 140 (5 ½”)
100 (4”) 100 (4”)
A A
min 2134 (84”)
BI36: 900 (35 ½”)
BI30: 750 (29 5⁄8”)
A
2134 mm (84”)
BI36: 900 mm (35 1/2”)
BI30: 750 mm (29 5/8”)
BI36: 1470 mm (57 7/8”)
BI30: 1320 mm (52”)
105°
BI36: 899 mm (35 3/8”)
BI30: 749 mm (29 1/2”)
2120 mm (83 1/2”) + 25 mm (1”)
610 mm (
24”)
610 (24”)
560 (22”)
1293 (50 7⁄8” )
474 (18 5⁄8”)
231 (9
1⁄8”
) +
25 (1”)
500 (19 ¾”)
248 (9
¾”
)
+ 25 (1”)
20 (¾”)
721 (28 3⁄8”) +25 (1”)
2120 (83 ½”) +25 (1”)
992 (39”)
BI36: 1470 (57
7⁄8”
)
BI30: 1320 (52”)
BI36: 160 (6 3⁄8”)
BI30: 125 (5”)
560 (22”)
610 (24”)
BI36: 899 (35 3⁄8”)
BI30: 749 (29 ½”)
10 (3⁄8”)
105°
Installation Guide
EnglishFrançais
Installation niche features: Integrated Series (BI)
BI30 w: 749 mm (29 1/2”)/ h: 2120 mm (83 1/2”)/ d: 610 mm (24”)
BI36 w: 899 mm (35 3/8”)/ h: 2120 mm (83 1/2”)/ d: 610 mm (24”)
BKI30 w: 749 mm (29 1/2”)/ h: 2120 mm (83 1/2”)/ d: 635 mm (25”)
BKI36 w: 899 mm (35 3/8”)/ h: 2120 mm (83 1/2”)/ d: 635 mm (25”)
30” Series w: 800 mm (31 1/2”) / h: 2260 mm (89”) / d: 800 mm (31 1/2”)
36” Series w: 950 mm (37 3/8”) / h: 2260 mm (89”) / d: 800 mm (31 1/2”)
30” Series up to 275 kg (606 lb)
36” Series up to 295 kg (650 lb)
North America Version: 115V 60Hz
North America Version: 15 A
from 0.05 MPa to 0.5 MPa (0.5 Bar - 5 Bar)
3/4” female attachment
Customized panels mounting Kit
Anti-tipping Kit (B04000200)
Lateral connecting kit (KCLIT/KCLIH)
4 mm
(1/8”) allen wrench
Phillips head screwdriver
wood and percussion drill
2.5 mm (1/8”) bit for wood
8 mm (3/8”) bit for walls
17 mm (3/4”) wrench
13 mm (1/2”) socket
area to be left clear for the anti-tipping brackets
Niche Height
Niche Width
Door Swing Clearance
Door Opening Angle
Width
Height
Depth with door (without panel)
