10.6 Repair tools chart
Idromeccanica Bertolini can directly supply, on request, all the tools and extractors indicated
in the table above.
Function Pump model Part number
Extractors to remove the packing seals
Pistons Ø 30 77.1494.97.3
Pistons Ø 36 77.3362.97.3
Pistons Ø 38 77.1495.97.3
Pistons Ø 40 77.3363.97.3
Pistons Ø 45 77.1178.97.3
Tools to mount the front seals
Pistons Ø 30 77.3008 A-B
Pistons Ø 36 77.3500 + 773501
Pistons Ø 38 77.3009 A-B
Pistons Ø 40 77.3500 + 773502
Pistons Ø 45 77.3010 A-B
Tools to mount the oil seals on the
plunger rods
CK Ø30-38 77.2331 D + 77.2331 B
CKL 77.2331 H + 77.2331 B
CK Ø45 77.2331 C + 77.2331 B
CPQ 77.2331 G + 77.2331 B
C 3006 Ø30-38 77.2331 D + 77.2331 A
C 3006 Ø45 77.2331 C + 77.2331 A
Tools to mount the oil seals on the shaft All 77.2337
