Movement debugging
Stroke, limit and reset
Setting stroke of each shaft of the machine will play the function of breadth protection (equals
to software limit). The travel parameters for each axis have been set up. Improper travel settings
may cause the equipment unable to work in full breadth or cutting head over-limit and collision.
Limit switch is the hardware sensor equipped on limit position of the two ends of each shaft.
After detecting limit triggering signal, the movement shaft will perform emergency stop to avoid
overreaching. Minimum one limit switch is needed for each shaft to indicate limit position of the
current shaft. The installation position of limit switch may differ due to different types of machines,
so the triggering signal. Therefore, configuration is needed.
Zero point of the machine is a referential point of a certain hardware fixed in processing
breadth. Generally, after power-on, “resetis needed for the machine to create coordinate of lathe.
The machines from our company generally take the limit switch position of each movement shaft
as the zero point of the machine.
Attentio
n
At ex-factory, configuration of parameters for stroke, limit and reset has been
already performed. Unauthorized change of parameters by user before
making clear its meaning is prohibited. Otherwise, failure of the equipment
may possibly be caused.
Motor shaft movement
When the equipment is powered on properly, start the computer and run the software CypCut.
In standby mode, the six direction keys on the software interface control the motion of cross beam
and the cutting head. If the four directions of X-axis and Y-axis and up/down motion of Z-axis are
normal, then the motion of X-axis, Y-axis and Z-axis motor is normal. If the motor shaft has any
problem in motion, please contact customer service staff.
Laser debugging
Laser debugging contains two aspects: light emitting test and light route adjustment. The
followings are the details for them.
Attention
Please turn on/off the equipment as required, or else it may cause equipment
malfunction.
