Chapter6 equipment Operation
6.1 Preparing Graphics
➢ Save the graphics to be processed in a format supported by PLT, DXF, GBX or AI with
graphics software;
➢ Run the cutting software CypCut, click [File] → [Import] in the top left corner, select the
type of processing graphics to import the graphics into the software;
➢ Set up “Lead”, “Sort”, “Optimize”, “Group” and other processing parameters as required
(see Optical Fiber Laser Cutter Software User Manual for specific settings).
6.1 Processing
➢ After setting the graphics, follow the power-on sequence and check if the laser power
is turned on, if the gas supply is turned on, and if the cutting gas is proper;
➢ Position the cutting head to start working position by moving the four arrow keys of X-
axis and Y-axis;
➢ Click [Frame] and check if the material under processing is placed in the format, and if
the cut graphics exceed the processing format;
➢ Then click the [Start] button to start processing.
6.1 Description of metal cutting process
We backed up the [Sample Parameters], [Factory Parameters Backup], and [Worktable
Blade Drawings] on the F disk of the computer. The user can open the [Sample Parameters] file,
and the cutting parameters are automatically imported to your computer for reference.
Chapter6 Startup and Cutting
Cutting process is closely related with the following elements:
➢ Laser power
➢ Focus position
➢ Height of the cutting torch
➢ Diameter of the cutting torch
➢ Type and quality of the cutting torch
➢ Auxiliary gas
