Automatic Uniform Sidedrive Carton Sealer (AS)
27
Drawings and Parts Lists
BELT DRIVE PARTS LIST
BMDBAS22D.1_0618
KEY NO. PART NO. QTY DESCRIPTION
1 K2225A00 1 COVER, BELT LT 2041L
2 K2226A00 1 COVER, BELT RT 2041L
3 K2203002 2 PLATE, FIXED TOP 1730L
4 K2201002 1 PLATE, FIXED BOTTOM LT 1730L
5 K2202002 1 PLATE, FIXED BOTTOM RT 1730L
6 C4215000 2 PLATE, BELT TENSION (TOP)
7 C4214000 2 PLATE, BELT TENSION (BOTTOM)
8 L1209000 1 PLATE, SUPPORT LT BELT BRACKET
9 L1210000 1 PLATE, SUPPORT RT BELT BRACKET
10 C4235000 4 PLATE, SUPPORT MOUNT M62X58
11 K2224000 4 BRACKET, BEARING HOUSING 6003Z
**12 14082A - PULLEY, ALUM FOLLOWER ASSEMBLY
13 14082 2 PULLEY, ALUM FOLLOWER M65.5X50
14 K2236000 2 SHAFT, FOLLOWER PULLEY M15X60
15 K2237000 4 SPACER, FOLLOWER M21.7X15X5
**16 K2211A00 - PULLEY, ALUM DRIVER ASSEMBLY W/ COUPLING
17 C4211000 2 PULLEY, ALUM DRIVER SBLT M65.5
18 K2213000 2 SHAFT, SIDE DRIVE SBT M17X97
19 14006 36 PULLEY, NYLON M65.5X48
20 14005 2 SHAFT, PLASTIC WHEEL M15X47
21 C4218000 6 SHAFT, IDLE ROLLER M15X60
22 2710033 2 BELT, 3700mmX2”
23 14021 8 BUSHING, METAL M15X54
24 C4222000 2 BUSHING, METAL M17.3X54
25 C4221000 4 SPROCKET, 15T BELT ADJ M2X15T
26 K2219000 2 SHAFT, BELT TENSION ADJ M12X77
27 A1122000 2 COUPLER, DRIVE SBLT M35X39
28 L070S 2 RUBBER, COUPLER SPACER M35X12
29 2702214 12 SCREW, FLAT HD M3X6
30 2701027 24 SCREW, SOCKET HD M6X12
** Sub-Assembly - Listed for reference only
