Automatic Uniform Sidedrive Carton Sealer (AS)
28
Drawings and Parts Lists
BELT DRIVE PARTS LIST (cont’d)
KEY NO. PART NO. QTY DESCRIPTION
31 2700002 6 SCREW, HEX HD M6X12
32 2702031 6 SCREW, FLAT HD M6X16
33 2704001 4 SCREW, SOCKET SET M6X6
34 2704002 4 SCREW, SOCKET SET M6X10
35 2705202 30 WASHER, SPLIT LOCK M6
36 2705102 30 WASHER, FLAT M6
37 2701018 6 SCREW, SOCKET HD M8X75
38 2701008 2 SCREW, SOCKET HD M8X80
39 2705203 8 WASHER, SPLIT LOCK M8
40 2705101 8 WASHER, FLAT M8
41 2705109 4 WASHER, FLAT M8X25X3t
42 2706002 2 RING, RETAINING M12
43 2706006 2 RING, RETAINING M17
44 27280031 4 BEARING, BALL 6003ZZ
45 27280094 4 BEARING, BALL 6202ZZ
46 2709001 2 KEY, M5X5X25
47 2709002 2 KEY, M5X5X40
BMDBAS22D.1_0618
To Next Page
