Automatic Uniform Sidedrive Carton Sealer (AS)
35
Drawings and Parts Lists
FLAP FOLDING PARTS LIST
KEY NO. PART NO. QTY DESCRIPTION
1 K2509000 1 BOARD, PROTECTOR (LH)
2 K2510000 1 BOARD, PROTECTOR (RH)
3 K2501001 1 FRAME, MINOR FLAP FOLDER
4 K6503000 1 KICKER, ARM FLAP FOLDER
5 K2508000 1 PLATE, MINOR FLAP FOLDER
6 K2502000 1 COVER, MINOR FLAP FRAME M802X7
7 K2507000 1 COVER, KICKER
8 54437 1 SHAFT, KICKER COVER M10X79
9 K6505000 1 SHAFT, CYLINDER MOUNT M10X36
10 20402 1 SHAFT, BUSHING M14X20
11 N1504001 1 SHAFT, KICKER M15X84
12 54436-5 1 SHAFT, COMP’N ROLLER M744X5/8
13 K2517000 1 GUIDE, FLAP FOLD- LH
14 K2518000 GUIDE, FLAP FOLD- RH
15 A1224000 2 BRACKET, BEARING 42X42Xt11
16 18012 1 INDICATOR, HEIGHT
17 N1508000 2 COVER, PLATE BEARING
18 N1505000 1 BASE, CYLINDER MOUNT
19 2920051 1 CYLINDER, AIR CDM2C40-85A
20 2908015 2 VALVE, SPEED CONTROL JSC 602
21 2911903 1 VALVE, SOLENOID VQZ3121-3Y-02
22 2916001 2 SILENCER, SOLENOID PT 1/8
23 2909332 3 FITTING, STRAIGHT 1/4X6
24 2701034 4 SCREW, SOCKET HD M5X16
25 2701035 2 SCREW, SOCKET HD M5X20
26 2701027 3 SCREW, SOCKET HD M6X12
27 2701020 2 SCREW, SOCKET HD M6X16
28 2701045 1 SCREW, SOCKET HD M6X40
29 2701030 10 SCREW, SOCKET HD M8X16
30 2701043 2 SCREW, SOCKET HD M8X30
BMFFAS22.D
To Next Page
