BestPack AS22-2 - Flap Folding Parts List (contd); Flap Folding Component Details (contd)

Automatic Uniform Sidedrive Carton Sealer (AS)
36
Drawings and Parts Lists
FLAP FOLDING PARTS LIST (cont’d)
BMFFAS22B
KEY NO. PART NO. QTY DESCRIPTION
31 2704001 2 SCREW, SOCKET SET M6X6
32 2702101 2 KNOB, LOCKING 3/8-13UNC
33 2703227 2 SCREW, OVAL HD M3X30
34 2703207 6 SCREW, OVAL HD PHILIP M5X6
35 2707045 2 NUT, HEX M3
36 2707020 1 NUT, HEX M6
37 2707022 2 NUT, HEX M8
38 2707103 6 NUT, HEX NYLOCK M8
39 2705125 2 WASHER, FLAT M3
40 2705103 12 WASHER, FLAT M5
41 2705102 6 WASHER, FLAT M6
42 2705101 14 WASHER, FLAT M8
43 2705109 2 WASHER, FLAT M8X25X3t
44 2705212 2 WASHER, SPLIT LOCK M3
45 2705201 4 WASHER, SPLIT LOCK M5
46 2705202 6 WASHER, SPLIT LOCK M6
47 2705203 15 WASHER, SPLIT LOCK M8
48 2706001 2 RING, RETAINING M10
49 2706004 2 RING, RETAINING M15
50 27280091 2 BEARING, BALL 6202ZZ
51 2728413 1 ROD END, PHS 14X1.5
