BESV CF1 - Disassembling Components: Motor; Motor Cable Disconnection and Preparation

Technical Manual - BESV CF1

16
3.3 Motor
1. Place the bike upside down, remove the bottom cover, and then disconnect motor
cable.
2. Remove the both side rubber cap and the flange nut.
3. Shift the derailleur to the highest speed.
Motor cable
