Technical Manual - BESV CF1
4
1.1.3 Pedaling Sensor
Model Kingmeter RPM
RPM Resolution 12 Impulses / Rotation
Weight 43 g
Operating Voltage 5 V
Clockwise Yes
Counterclockwise No
Direction Yes
1.1.4 HMI
Model BESV HMI
Operating Temp. -15°C ~ 70°C (5°F ~ 158°F)
Storage Temp. -15°C ~ 80°C (5°F~ 176°F)
Storage Humidity 20% ~ 80%
Display Type Handlebar Switch and Power Button LED Indicator
Lighting Control Integrated PWM Headlight + Taillight control
I/O Cable Connector
1 8 Pin Handlebar Switch
2 6 Pin Power Button
3 6 Pin Power + UART communication cable to motor controller
4 2 Pin Rear Light
5 3 Pin Front Light
Information Battery Capacity, Assistance Level, Version Query
Assistant Level 3 Assistance Level
2
1
3
4
5
