Technical Manual - BESV CF1

3
1.1 Specification
1.1.1 Controller
Model A-Type
Operating Temp. -15°C ~ 50°C (5°F ~ 122°F)
Storage Temp. -15°C ~ 100°C (5°F~ 212°F)
Storage Humidity 10% ~ 85%
ROHS Confirms the ROHS of PTC
Function
1. Over voltage protection
2. Over current protection
3. Stall protection
4. Speed limitation
5. UART communication
6. BLDC driver with hall
7. Battery Communication
Output Power 250W (Peak 380W)
Operating Voltage 36V Regular (Range: 30 to 42V)
Efficiency 92%
1.1.2 Motor
Model 250W Front Gear
Operating Temp. -15°C ~ 80°C (5°F ~ 176°F)
Storage Temp. -15°C ~ 100°C (5°F ~ 212°F)
Storage Humidity 10% ~ 90%
Fork Size 36 H
Weight 2 kg
ROHS < 45 db
Noise 120 ~ 450 RPM
Max RPM 40 Nm
Max Torque 180 ~ 300W
Max Output 36 V Regular (Range: 24 to 48V)
Operating Voltage > 80%
