BESV CF1 - Troubleshooting: Motor Motion Resistance; Heavy Motor Motion Resistance Diagnosis

Technical Manual - BESV CF1

27
Issue Step Check step Action
The motion
resistance is
heavier while
motor is
rotating.
1
Use meter to check if the cable of motor is
short in circuit.
If yes, please replace the
motor.
If no, please progress the next
step.
2
Please contact the manufacturer for the
criterion of inductance, and measure the
inductance with LRC meter, and then check
if the value exceeds the criterion.
If yes, please replace the
motor.
If no, please progress the next
step.
3
Use scope to measure the EMF of motor and
check if the signal is correct or not.
If yes, please progress the next
step.
If no, please replace the motor.
4
Open the housing of motor, and use meter to
confirm any short circuit between silicon
steel and any cable.
If yes, please replace the
motor.
If no, please contact with the
manufacturer.
