QUICK REFERENCE PARTS LISTING
Heat Exchanger & K
eel Cooled Beta 10, BZ482, Beta 16, BD722, & Beta 25
In all cases please quote Beta Marine WOC “K” number and Engine Type
Description Part Number Qty per Engine
Alarm board
200-04655 1
Relay 12 Volt 40A (28Ra) fitted to rear of panels
200-87020 1
Stop Solenoid (energised to stop fuel)
600-81950 1
F
use
(Blade) 40 Amp
200-00959 1
Standard Engine Harness
200-98380/01 1
65 Amp Alternator Sub Loom (external fan)
200-01196
1
1m Panel Extension Loom
200-04588/01
2m P
anel
Extension Loom
200-04588/02
3m Panel Extension Loom
200-04588/03
4m Panel Extension Loom
200-04588/04
Water Temperature Switch (Panel A, ABV & ABVW) NOT Beta 16 or 25
200-01133
1
Water Temperature Switch with single terminal Beta 16 & Beta 25)
600-62820
Water Temperature Sender (Panel C & B)
200-94360
Oil Pressure Switch (Panel A, ABV, ABVW, & B)
600-62670
1
Oil Pressure Sender (Panel C)
200-94350
Standard 50mm Water Injection Exhaust Bend
202-02458
1
5” High Rise 50mm Water Injection Exhaust Bend
202-92400/22
Exhaust Bend Gasket
600-62620 1
Drive Plate 22-B-60 - PRM / ZF
206-91950
1
Drive Plate 22-B-4 - TMC / ZF
206-97041
Flexible Mountings (Trelleborg RA60)
213-93440 4
Rocker Cover Gasket BZ482
600-01055
1
Rocker Cover Gasket Beta 16
600-05467
Rocker Cover Gasket BD722
600-00607
Rocker Cover Gasket Beta 25
600-05468
Head Gasket Beta 10, BZ482
600-00409
1
Head Gasket Beta 16
600-05469
Head Gasket BD722
600-01562
Head Gasket Beta 25
600-05470
T
op Gasket Set
BZ482
600-00383
1
Top Gasket Set Beta 16
600-05471
Top Gasket Set BD722
600-00395
Top Gasket Set Beta 25
600-05472
Lower Gasket Set BZ482
600-01056
1
Lower Gasket Set Beta 16
600-05473
Lower Gasket Set BD722
600-00394
Lower Gasket Set Beta 25
600-05474
Manuals
Operators Maintenance Manual
221-02887 1
K
ubota W
orkshop Manual
, Beta 10 / BZ482, BD722
600-00756
1
K
ubota W
orkshop Manual
, Beta 16 & Beta 25
600-05475
Kubota Spare Parts Manual - Beta 10 & BZ482
600-02437
1
Kubota Spare Parts Manual – Beta 16
600-05476
Kubota Spare Parts Manual – BD722
600-02438
Kubota Spare Parts Manual - Beta 25
600-05477
