Spanner torque settings
Tightening Torques for general use bolts and nuts
ITEM Size x Pitch kgf
.
mft
.
lbs N
.
m
M6 (7T) : 6mm (0.24in) – 1.0~1.15 7.2~8.3 9.8~11.3
M8 (7T) : 8mm (0.31) – 2.4~2.8 17.4~20.3 23.5~27.5
M10 (7T) : 10mm (0.39in) _ 5.0~5.7 36.2~41.2 49.0~55.9
M12 (7T) : 12mm (0.47in) _ 7.9~9.2 57.1~66.5 77.5~90.5
Tightening Torques for special use bolts and nuts
Head Bolts M8 x 1.25 3.8 ~4.3 27.5~31.1 37.3~42.2
Bolts, Connecting Bolts M7 x 0.75 2.7~3.1 19.5~22.4 26.5~30.4
Bolts, Flywheel M10 x 1.25 5.5~6.0 39.8~43.4 53.9~58.8
Bolts 1, Bearing Case M6 x 1.0 1.3~1.6 9.4~11.6 12.7~15.7
Bolts 2, Bearing Case M7 x 1.0 2.7~3.1 19.5~22.4 26.5~30.4
Nozzle Holder Assembly M20 x 1.5 5.0~7.0 36.2~50.6 49.0~68.6
Caps Nuts, Head Cover M6 x 1.0 0.4~0.6 2.9~4.3 3.9~5.9
Glow Plugs M8~1.0 0.8~1.5 5.8~10.8 7.8~14.7
Oil Switch PT 1/8 1.5~2.0 10.8~14.5 14.7~19.6
Nuts, Rocker Arm Bracket M6 x 1.0 1.0~1.15 7.2~8.3 9.8~11.3
Bolts, Idle Gear Shaft M6 x 1.0 1.0~1.15 7.2~8.3 9.8~11.3
