have a layer of friction material at least 2 mm thick. If it is
thinner than this, replace the pads immediately.
Note:
Check the brakepads at the intervals given in the
table on page 29.
Replacing the brakepads
To replace the pads, follow the steps below:
- Remove the disc cover and the caliper by unscrewing
the two bolts indicated by the letter A and slacking off
screw B.
- Slide out the retaining pin (C).
- Undo screw B.
- Take out the pads (D) and replace them.
- To refit the pads, follow these steps in reverse.
Note:
Take particular care to refit the retaining pin cor-
rectly, to avoid braking problems.
If the brake disc is removed, some suitable thread
lock should be applied to the bolts when refit-
ting.
