VEHICLE IDENTIFICATION DETAILS
Frame identification
The frame identification details (A) are stamped on
the right-hand side of the headstock.
ENGINE IDENTIFICATION DETAILS
The engine identification details (B) are stamped in
the area indicated in the picture.
CONSOLE AND CONTROLS
1 Clutch lever
2 Front brake lever
3 Throttle twistgrip
4 Hot start lever
5 Lights on/off/engine stop
PRINCIPAL PARTS
1 - Filter box 2 - Fuel tank 3 - Fuel filler cap 4 - Silencer
5 - Kickstart lever 6 - Filter cover
1
6
2
3
5
4
