Better BT-1 - Automatic Status Back (ASB); Peripheral Device Status

BT-1 user manual
Page 41 of 70
5
6
7
-
-
-
Undefined.
Off
On
-
00
40
-
0
64
-
Temperature is normal.
Temperature＞60°.
Undefined.
For example
：
return “0x04” is means paper out.
GS a n
[Name]
Enable/Disable Automatic
Status Back(ASB)
[Format]
ASCII:
GS a n
29 97 n
1D 61 n
Decimal:
Hexadecimal:
0≤n≤255
[Range]
[Description]
n definition as follows:
When ASB is enabled, the printer will send the changed status to PC
automatically.
Value
Bit
Function
0
1
0
1
-
-
-
-
-
-
2
Disable/Enable ASB
-
Disable
Enable
3
-
4
-
-
5
Disable/Enable RTS as flow control
-
Disable
-
Enable
-
6
-
7
ESC u n (for Drawer)
[Name]
Transmit peripheral devices status
[Format]
ASCII:
ESC u
n
n
Decimal:
27
117 n
Hexadecimal:
0=0, 48
1B
75
[
Range]
[Description]
Transmits the status of the drawer kick-out connector pin 3 as 1byte of
data when n=0, 48.this allows the host to determine the status of a
peripheral device.
n is used as follows:
Bit
On/off
Hex
Decimal
Function
0
Off
On
-
00
01
-
0
1
-
Drawer kick out connector pin 3 is low
Drawer kick out connector pin 3 is high
Undefined
0
1-3
4
Off
-
00
-
0
-
Not used. Fixed to off
Undefined
5-6
7
Off
00
0
Not used. Fixed to off
