SP - 27
Conexiones de dispositivos
Diagrama de cableado
PIN PART A
1 NC 2 NC 3 NC 4
Battery +12V
5 P.ANT 6 Illumination 7
ACC
8 GND
PIN PART B
1 Rear R+ 2 Rear R- 3 Front R+ 4 Front R- 5 Front L+ 6 Front L- 7 Rear L+ 8 Rear L-
AUX IN
Red
Red(R)
Blue
Yellow Yellow Yellow
White(L)
Red(R)
White(L)
Red(R)
White(L)
Green
White
FRONT OUT
GPS ANTENNA
Black
MICROPHONE
RADIO ANT
Black Black
Black
3G/WIFI 3G/WIFI
Black
REAR OUT
Grey
VIDEO OUT
Black
VIDEO IN
Black
CAMERA VIDEO
Black
SUB WOOFER
Black
Orange Pink
Black
PARKING
REVERSE
SWC
Microphone
Key A
Key B
GND
