Bewator Bewacard BC610 - Wiring Diagram and Terminal Functions

BC610 Installation and User manual 9
Installation continued
The numbers below refer to the numbers on the wiring diagram.
1
Electric locking device. Dashed line shows connection to
locks with fail unlocked operation.
2
Power in, terminal block nos. 1 and 2.
3
Exit Request button. To operate short terminal nos. 6 and 9.
Optionally, a time-clock can be connected to control a door
that should be permanently open.
4
Input for reader inhibit. To operate short terminal nos. 7 and
9. The red LED on the fascia will be lit.
5
Duress output. Used for activating an external alarm. Use an
E7 relay. Connect between terminal nos. 8 and + (1).
6
Remove the jumper if back lighting is not required.
7
Control input for
Common code
. Terminal nos. 10 and 13
open:
Common code
enabled. Terminal nos. 10 and 13 linked:
Common code
disabled.
8
Control input of
Card
and
Card + PIN
security levels.
Terminal nos. 11 and 13 open:
Card
. Terminal nos. 11 and 13
linked:
Card + PIN
.
9
Control input for
Toggle function
. Link terminal nos. 12 and
13 to activate the toggle function.
10
The SW1 push button. Used to erase the memory and to set a
new password.
11
Tamper switch. Normally closed when the housing is closed.
