10 Connectivity and Information Commands
Note
When connected via USB, it might be necessary to unplug/plugin the USB cable after
port after the restart command and before the Quinta CU appears as a virtual COM
device again.
Example
2.3 ~^d command
Power-Off Microphone Unit
Sending this message to the Quinta control unit will trigger a power off of all
Microphone Units which are in RF reach and are therefore connected to the control unit.
Note: T ~ ^
command-string and need to be sent as usual ASCII characters.
Important Note
The ~^d command can be executed in broadcast as well as in unicast mode; please
refer to chapter 3.2 for details.
Without selecting a specific MU with the M command, the system is in broadcast mode
by default and all MUs are addressed.
Power-off all MUs
>> Triggers Q CU-reply since an allocation/deallocation
has occurred
