13 Connectivity and Information Commands
Examples
2.6 x message
Microphone Unit Status Message
The x message is automatically generated and sent periodically (about every 20
seconds) by MUs to CU. These messages are also output via RS232 and do not require
the system to be unlocked. It provides all important information about each MU in the
RF range.
Communication direction
MU -> CU -> Controller
Syntax
Description
x muad m f v
Microphone unit status messages
Parameters
Description
muad
Source MU ID
[range: 0x000001 0xFFFFFF]
m
MU flags (16 bits)
[range: 0x0000 0xFFFF]
f
MU status flags (8 bits)
v
Version information
Quinta CU is connected
Transmit:
j 3 D<CR>
Receive:
<CR><LF>
Full mode<CR><LF>
>
Quinta RS is connected
Transmit:
j 3 D<CR>
Receive:
<CR><LF>
Light mode<CR><LF>
>
