35 Conference Control Commands
bit 11-8 HWType: Hardware type
bit 7 N.U.: not in use, unimplemented bit
bit 6-4 MUZone: represents the zone in which the MU is used
>> These zones are used, for example, to sound different locations, which
are then discreetly assigned to the zones. When the zoning function is
enabled, each output is assigned to a specific zone. In each zone,
several microphone units are mixed together according to their division.
For example, a zone can also be assigned to the headphone output of
the microphone units.
bit 3-0 AllocationMode
>> The AllocationMode refers to the assignment of MUs to a specific func-
tionality. This functionality is important when assigning audio streams,
since a stream is permanently reserved for a chairman.
0000
Single MU (1 button)
0001
Double MU (2 buttons)
0010
Chairman MU (3 buttons)
0011
Revoluto MU (1 button)
0100
Revoluto MU (2 buttons)
0101
Reserved
0110
Reserved
0111
Reserved
1000
Reserved
1001
Reserved / Test MU
> 1001
Generic MU
000
MU Zone 1
001
MU Zone 2
010
MU Zone 3
011
MU Zone 4
0000
Single Delegate (SDel)
0001
Double Delegate left (DDelL)
0010
Chairman (Chrm)
1001
Double Delegate right (DDelR)
