Transport, Installation and Connection
4-6
The use of a ball flange (
optional, Part No.: 6590-9020-01
)
allows adjustments to be carried out easily in order to me-
chanically obtain the optimum observation point. The
compact flame controller is supplied complete with a
quick-installation flange. This guarantees quick and easy
removal of the compact flame controller. It has a purge air
connection whose special design prevents soiling of the
lens without the possibly dust-laden purge air being able
to damage the lens. If temperatures of over 50 °C occur at
the compact flame controller caused by the heat dissipa-
tion of the sighting tube despite the inflow of cooling air, a
heat insulator (optional, Part No.: B 512.1) must be em-
ployed. At pressurised firing installations, an additional 3-
port shut-off device (optional, Part No.: B 520) should be
installed for the sake of safety. This prevents an escape
of hot gases after the removal of the compact flame con-
troller and provides additional cooling and purging of the
installation.
The entire mechanical peripheral system can be supplied
by BFI Automation.
